| Estimated Delivery | Add | |||
|---|---|---|---|---|
| 102161072 | DP 251 M | 102161072 | DP 251 M | — |
£456.00
Save £225.00 (33% off)
|
|
| 102161042 | DP 151 M | 102161042 | DP 151 M | — |
£395.00
Save £195.00 (33% off)
|
|
| 102660880 | DP 102 M | 102660880 | DP 102 M | — |
£303.00
Save £150.00 (33% off)
|
|
| 102660860 | DP 82 M | 102660860 | DP 82 M | — |
£201.00
Save £99.00 (33% off)
|
Performance
The DAB DP series consists of durable submersible drainage pumps designed for removing clean or lightly contaminated water in residential and light commercial environments. With flow rates up to 4.3 m³/h and support for horizontal installation, these pumps are ideal for basements, tanks and light duty irrigation systems.
Applications
- Basement and sump drainage
- Flood water removal
- Irrigation water recovery
- Emptying tanks, pits and reservoirs
Construction
Constructed from wear resistant materials, the DP series includes a cast iron pump body and motor support, technopolymer impeller and diffuser plus a stainless steel wear ring. A carbon and ceramic mechanical seal ensures long term durability. All models are suitable for fixed horizontal installation.
Key Specifications
- Flow rate: up to 4.3 m³/h
- Liquid temperature: 0°C to +35°C for domestic use, up to +40°C for other applications
- Maximum ambient temperature: +40°C
-
Maximum operating pressure:
- DP 82 and DP 102: 6 bar (600 kPa)
- DP 151 and DP 241: 8 bar (800 kPa)
- Installation: fixed horizontal position
- Motor protection rating: IP44
- Terminal block protection: IP55
- Insulation class: F
-
Power supply options:
- Single phase: 220–240 V, 50 Hz
- Three phase: 230–400 V, 50 Hz
Delivery
Order the DAB DP Series submersible drainage pump from pumpsandgearboxesdirect.com with free UK mainland delivery.
