CALPEDA

SKU:MXH-F 4803/A | 62245031100

MXH

Cast Iron

Delivery Time: For delivery lead times on this product, please contact the office.

MXP Range: Horizontal Multi-Stage Close Coupled Pumps

Key Features:

• Compact Horizontal Design Space-saving, close-coupled pump with a one-piece barrel casing.

• Stainless Steel Construction AISI 304 chrome-nickel stainless steel ensures durability and corrosion resistance.

• Efficient Multistage Operation Stages made from Noryl (PPO-GF20) for lightweight, high-performance pumping.

• Versatile Applications Ideal for domestic water supply, gardening, and irrigation.

• High Reliability Designed for continuous duty operation.

Applications:

• Water supply systems

• Domestic and garden use

• Irrigation and sprinkler systems

Operating Conditions:

• Liquid Temperature: 0°C to +50°C

• Ambient Temperature: Up to 40°C

• Maximum Pump Casing Pressure: 8 bar

• Continuous Duty

Materials & Construction:

Motor Details:

• 2-Pole Induction Motor, 50 Hz (‰ˆ 2800 rpm)

• Three-Phase (MXP): 230/400V ±10%

• Single-Phase (MXPM): 230V ±10% with built-in thermal protector

• Capacitor inside terminal box

• IE3 efficiency class (IE2 up to 0.65 kW)

• IP54 protection, Insulation Class F

• Designed for operation with a 1.1 kW inverter

• Complies with EN 60034-1, EN 60034-30-1, EN 60335-1, and EN 60335-2-41

MXH Range: Horizontal Multi-Stage Close Coupled Pumps

Key Features:

• Robust Stainless Steel Construction AISI 304 chrome-nickel stainless steel, with AISI 316L steel for MXHL models.

• Compact and Durable Design Single-piece barrel casing with front suction and radial delivery at the top.

• High-Performance Pumping Reliable operation with continuous duty capability.

• Wide Application Scope Suitable for domestic, civil, industrial, and irrigation systems.

• Optional Frequency Converter Available upon request.

Applications:

• Water supply systems

• Clean liquids without abrasives

• Domestic, civil, and industrial applications

• Gardening and irrigation

Operating Conditions:

• Liquid Temperature: -15°C to +110°C

• Ambient Temperature: Up to 40°C

• Maximum Pump Casing Pressure: 8 bar (10 bar for MXH 20, 32, 48)

• Continuous Duty (S3 60% for single-phase pumps up to 1.5-1.8 kW)

Motor Specifications:

• 2-Pole Induction Motor, 50 Hz (n ‰ˆ 2900 rpm)

• Three-Phase (MXH): 230/400V ±10% (up to 3 kW), 400/690V ±10% (3.7 to 7.5 kW)

• Single-Phase (MXHM): 230V ±10%, with thermal protector

• Capacitor inside the terminal box

• Insulation Class F

• Protection IP54

• Motor suitable for frequency converter operation from 1.1 kW

• IE2 efficiency class for single-phase motors up to 1.1 kW

• IE3 efficiency class for three-phase motors (IE2 up to 0.65 kW)

• Complies with EN 60034-1, EN 60034-30-1, EN 60335-1, EN 60335-2-41

Special Features on Request:

• Pumps with Victaulic couplings (-V) for MXH versions 32, 40

• Pumps with flanged ports (-F) for MXH versions 20, 32, 40

• Other voltage options

• 60 Hz frequency version available

• IP55 protection

• Special mechanical seals

• Pump casing seal rings in FPM

• Higher or lower liquid or ambient temperatures

• Motor suitable for frequency converter operation up to 0.75 kW

Materials & Construction:

Designation Example: MXH(L) (-V, -F) EI 206/B

• MXH = Series

• L = AISI 316 stainless steel version for MXH 2, 4, 8

• (-V) = Version with Victaulic couplings for MXH 32, 40

• (-F) = Version with flanged ports for MXH 20, 32, 40

• EI = With frequency converter I-MAT

• 2 = Rated capacity in m³/h

• 06 = Number of impellers
